BELLA-HD Universal HDMI Set Top Box Interface

For elegant signal distribution. | PD295-004

Request A Quote Download Overview Sheet

Deliver beautiful HD 1080 signal, farther.

  • Provides higher resolution than using an NTSC modulator to transmit video to hospital TVs
  • Connects to TV via CAT6a cable and provides homeruns up to 250 ft, no POE; if existing CAT5e, 200 ft.
  • Combines streaming HDMI video and Set Top Box control over CAT cable
  • Eliminates the need for a modulator or HDMI Extender
  • Eliminates need for patient remote
  • Provides seamless IR control of satellite receivers and cable set top boxes from the television’s keypad, remote and/or pillow speaker
  • Reduces headend complexity
  • Fits all standard mini-mod racks
  • Powered by chassis power supply when mounted in a standard chassis. (If stand alone, a PDi power cord must be ordered separately PD106-747).

For use with all PDi televisions with a CCI port. CCI is included on A-Series and optional on all PDi arm-mounted sets.



Part Number: PD295-004

Dimensions (WxLxH): 1.03” x 7” x 3.46”

Weight: 8.4 oz
